FL0240

Flexible Decor Lights

Description

Flexible Decor Lights, application designed for Airbus A318, A319, A320, A321, A330, A340, A380

Flexibler LED-Lichtstreifen in leuchtendem Gelb, spiralförmig auf einer hellblauen Fläche angeordnet.

Key features

Electrical

  • 1 m pigtail or 500 mm with ABS connector
  • PWM dimming possible
  • protection against overload, short-circuit and inverse polarity

Mechanical

  • bending radius of 100 mm in all directions
  • protective silicone housing
  • fully qualified acc. to RTCA-DO160

Other

  • decorative and accentual lighting all over the aircraft cabin
  • 16.7 million light colours (24 bit) available
  • MTBF > 50,000 OH

Technical data

Mechanical dimensions

  • length: base element 180 mm extension element 120 mm
  • max. lenght: 4,980 mm (base element + 40 extensions)
  • width: 15 mm
  • height: 18 mm incl. brackets
  • weight: base element á 75 g extension element á 25 g

Electrical data

  • voltage: 28 V DC
  • power consumption: max. 10 W / m

Downloads

Download technical information
