CL6050 – AES Aircraft Elektro Elektronik System GmbH

CL6050

LED Ceiling Lights

Description

LED Ceiling Lights, application designed for Airbus A350

Key features

Electrical

active temperature control
PWM dimming possible (DC variant only)
ageing compensation possible

Mechanical

general cabin as well as decorative lighting
CAN Bus and CIDS possible
fully qualified acc. to RTCA-DO160 and ABD0100

Other

the ceiling lights are designed to substitute normal fluorescent lamps
light colour cool white, warm white, RGBW
MTBF > 78,000 OH

Technical data

Mechanical dimensions

length: 1180 | 873 | 566 | 292 mm
height: 32 mm
height: 32.2 mm incl. brackets
weight: 0.6 | 0.45 | 0.3 | 0.17 kg

Electrical data

voltage: 28 V DC or 115 AC
power consumption: 29.5 | 22 | 15 | 8 VA / W
